Aluminum Foil Bag Three Side Sealing Mayonnaise Tomato Sauce Sachet Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Aluminum Foil Bag Three Side Sealing Mayonnaise Tomato Sauce Sachet Packing Machine,It is applicable for packing the semi-fluid like hairdressing water, hair conditioner, lotion, soy sauce, cough syrup, agricultural chemicals, wine, sauce, cheese, peanut butter, ketchup, bean paste and chilli sauce etc
It has pneumatic transmission system with a reliable operation being ensured. A computer with an easy operation and adjustment being provided controls it, the performance is stable, and the quality is reliable.
Staples adjusting of the packaging speed.
Adopting proper bag length controlling technology, the bag length can be adjustable stepless, precise length, convenient adjustment.
Aluminum Foil Bag Three Side Sealing Mayonnaise Tomato Sauce Sachet Packing Machine
Specifications for Aluminum Foil Bag Three Side Sealing Mayonnaise Tomato Sauce Sachet Packing Machine
Model | HY-QY50 | HY-Y50 |
Filling range | 1-50ml | 1-50ml |
Sachet size | W：30-100mm L：30-150mm | W：30-100mm L：30-150mm |
Max. film width | 220mm | 220mm |
Sachet type | 3 sides / 4 sides | 3 sides / 4 sides |
Filling method | Piston pump / magnetic pump | Piston pump / magnetic pump |
Control | SIEMENS PLC + TOUCH SCREEN | EASY PACK CONTROL |
Capacity | 30-50ppm | 30-50ppm |
Power | 220V50-60HZ/1.0KW | 220V50-60HZ/1.0KW |
Air | 0.3m³/min 0.6-0.8Mpa | 0.3m³/min 0.6-0.8Mpa |
Materials | Case and contacting parts SUS304 | Case SUS202;Contacting parts SUS304 |
Dimension(L*W*H) | 880*700*1750mm | 670*850*1655mm |
Weight | 250KG | 200KG |
Bag sample as below:
1. Machine Introduction:
Aluminum Foil Bag Three Side Sealing Mayonnaise Tomato Sauce Sachet Packing Machine，it is full automatic and pack liquid from 1ml to 50ml,bag type is three side sealing.sachet bags
trying to find a economical packing machine model but with high quality and assured service for your liquid?Chose this machine,it is the best and first choice for you.
This liquid packing machine was using liquid pump feeding system, which is control by pneumatic and working independent. can using to filling: milk, ketchup, water, sauce,cream, shampoo.The Packing weight tolerance only ± 1%.
Client just need install packing film with machine, then it will automatic to achieved: bag forming, weight metering, product filling, bag sealing, counting, cutting and batch number printing. Bag type like: pillow bag, 3/4 sides seal bag, linked bag was all available!
2. Our company strength:
A big factory with 20 years experience.with a big professional engineers team.can solve all packing idea for you.Just need to know your packing idea.
24 hours standby for machine inquiry and technicial support need.
Provide on site installation and debugging service.
All machine with CE certification.
3. Frequently Asked Question
Price item options: EXWORK,FOB,CIF,CFR
Payment terms : T/T 30% deposit, 70% balance before shipment.
Delivery Time : 10- 15 days depending on packing requirement.
Shippment : By sea or by air. E. Warranty time :One year free for replacement of wearing parts, cost price beyond warranty
