Automatic Multi Lanes Sachets Ketchup Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Automatic Multi Lanes Sachets Ketchup Packing Machine, Our sachet machine is widely used in daily-chemicals, chemicals, foods, health care products, medicine, cosmetics industries like water,honey,fruit juice,sauce,cream,fliud,shampoo,bath foam,tomato sauce(ketchup),fruit jelly,soysauce,oral flauid,butter,facial creams and liquid detergent and other any liquid like water and any other paste like ketchup
Automatic Multi Lanes Sachets Ketchup Packing Machine
Specifications for Automatic Multi Lanes Sachets Ketchup Packing Machine
Model | HY-Y880 | HY-Y1080 |
Filling range | 1-50ml | 1-50ml |
Rows | 1by4, 1by6 | 1by6, 1by8, 1by10 |
Sachet size | W：25-100mm L：30-170mm | W：25-90mm L：30-170mm |
Max. film width | 880mm | 1080mm |
Sachet type | Four sides seal | Four sides seal |
Filling method | Piston pump | Piston pump |
Capacity | 80-120ppm | 200-350ppm |
Power | 220V50-60HZ/4.5KW | 220V50-60HZ/4.5KW |
Air | 0.6m³/min 0.6-0.8Mpa | 0.6m³/min 0.6-0.8Mpa |
Dimension(L*W*H) | 1500*1620*2500mm | 1600*1820*2500mm |
Weight | 600KG | 650KG |
Function and Feature for Automatic Multi Lanes Sachets Ketchup Packing Machine
1)Be able to weight, make, fill, seal, cut off,print the date and lot number,cut easy tearing notch and count automatically.
2)To has mark control system(photocell) which can get the complete trade mark design and fix the length of the bag to be cut off.
3)To adopt step motor and driver so that we can adjust the speed of the machine directly. don't need to change any other parts on the machine.
4)Intelligent temperature control by temperature controller to make heat balance better.use bilingual display screen control system and stainless steel304 cabinet
5)Fine packaging performance ,low noise ,clear sealing texture and strong sealing performance
6)With black ink printer(be able to print the date and batch number-3lines)
