Automatic multi lanes trucks particle medicine packing machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Automatic multi lanes trucks particle medicine packing machine,be equal to many sets single lane granular packing machine,always used for some food,medicine,health food,cosmetics field,high speed packing machine,low price granular packaging machine.
Servo motor packing machine with high accuracy.high speed,long life.A good and big packing machine factory in China.
Automatic multi lanes trucks particle medicine packing machine
1. This is multi lanes granular packing machine,normally to pack some stick bags like stick sugar,coffee,salt,etc.if you want to pack Three-side sealing,four-side sealing bag type,need to change another machine,as the instructure is different.
2.Step-by-step drive structure controls the length of sack. Photoelectric tracking and orientation.Servo motor is to push bag.accuracy，can automatically finish the function of bag-making, measuring, feeding, sealing, cutting and counting;
3.Suitable for packing granule materials in the industry of food, medicine and chemic, such as oatmeal, puffed food, granulate sugar, medicine, tea, albumen powder, coffee and flavoring and so on.
Application:
This machine is widely used in pharmaceutical and food industry to pack granule products in bags,very fast,we can produce 6 lanes,8 lanes,10lanes and 12 lanes,200-500bags/min.this machine especially for some pharmaceuticals industry,they use it to pack probiotics.5g ,8g for one bag.whole set machine with high speed and hig accuracy.you can change the bag length by yourself.
Characteristics:
The machine is designed to perform in stable quality with simple operation manual.Options are available for nun-cutting link packs,gas filling device.Atomatic bag forming,volumetric filling,sealing and code stamping are continuously completed.Simple mechanical structure,easy for cleaning and maintenance.
With big touch screen,you can change everything on the touch screen,Siemens PLC control system.Multi lanes need high technology,Not each company can do multi lanes
particle medicine packing machine well,but we are a big packing machine factory with long history,have produce many sets of this machine,if you have time,you can come to our factory to check this machine,have them in stock.
Main parts of the this multi lanes granular packing machine as below:
PLC | Siemens | smart200 |
Touch screen | Siemens | smart10001E |
temperature control | Omron | E5CWL-QITC |
Relay | Omron | MY2N-GS |
Servo motor 1.5KW | Panasonic | A6 series |
Servo motor 400W | Panasonic | A6 series |
Switch | Schneider | ABL 2REM24065H |
photoelectricity | Sunx | LX-101 |
Air cylinder | AirTAC | |
button | Schneider | 2B2-BS54C |
Start button | Schneider | LAY50-22D-11D |
material | 304SUS | Whole set machine |
Specifications
Model | HY-YK520 | HY-YK720 |
Filling range | 1-20ml | 1-50ml |
Rows | 1by6 | 1by6, 1by8, 1by10 |
Sachet size | W：25-38mm L：30-170mm | W：25-55mm L：30-170mm |
Max. film width | 520mm | 720mm |
Sachet type | Stick with round corners | Stick with round corners |
Filling method | Volumetric cups | Volumetric cups |
Capacity | 120-200ppm | 200-350ppm |
Power Voltage and consumption | 220V50-60HZ/4.5KW | 220V50-60HZ/4.5KW |
Air pressure and consumption | 0.6m³/min 0.6-0.8Mpa | 0.6m³/min 0.6-0.8Mpa |
Dimension(L*W*H) | 1410*1700*2500mm | 1540*1700*2500mm |
Weight | 600KG | 650KG |
Packaging film materials | PE laminated film, such as PET/AL/PE, PET/PE, Nylon/PE, etc. Thickness: 0.08~0.12mm(3 or 4 layers) Inner core diameter：75mm Outer roll diameter：500mm | |
With automatic loader and finished belt to you for free
