Automatic Small Sachets Troche Food Chewing Gum Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Automatic Small Sachets Troche Food Chewing Gum Packing Machine
Heyi packing machine factory's HY series Automatic Pill Troche Food Chewing Gum Packaging Machine is widely used to pack tablets or pills in the fields of food, daily chemical, medicine, agricultural chemicals etc. It is suitable for heat sealable compound materials such as single Paper/PE, Cellophane/PE, Aluminum foil /PE, BOPP/PE, Nylon/PE etc.
the machine can counting pills one by one then pack them automatically.per the diemeter of the pills,normally 1-20 pcs for one bag is ok
Automatic Small Sachets Troche Food Chewing Gum Packing Machine
Main Features
1,PLC Computer control system and English-Chinese (you can put two language into the system as you want)touch screen for easy operation without stopping the Automatic Small Sachets Troche Food Chewing Gum Packing Machine .The PLC controller has the advantages such as setting the length of the bag; the out put alarm and the speed and quantity with buttons;
2,Intelligent PID temperature controller for easy adjustment and good application to various laminated film and paper.
3,Packaging diversification, such as back-seal bag, side gusseted bag, linked bag, hole punched bag,etc.
This machine can finish : forming bag--measuring--material filling—sealing—counting—date code printing, all the work automatically;
4, Photoelectric and tracing system or computer system can be provided without your specific requirements.
5. This machine can be installed to code printer for 1-3 lines characters such as production and expiry date according to your special request.
6.Unique in-laidembedded mouth sealing,enhanced hot sealing mechanism,intelligent temperature control,featuring fine heat balance,fine packaging performance,low noise,clear sealing texture and strong sealing performance.
Specifications for Automatic Small Sachets Troche Food Chewing Gum Packing Machine
Model | HY-PJ50 | HY-PB50 |
Filling range | 1-10pcs | 1-10pcs |
Sachet size | W：30-100mm L：30-150mm | W：30-100mm L：30-150mm |
Max. film width | 220mm | 220mm |
Sachet type | 3 sides / 4 sides | Pillow stick |
Filling method | Counting plate | Counting plate |
Control | Easy Pack | Easy Pack |
Capacity | 30-40ppm | 30-40ppm |
Power | 220V50-60HZ/1.0KW | 220V50-60HZ/1.0KW |
Air | 0.3m³/min 0.6-0.8Mpa | 0.3m³/min 0.6-0.8Mpa |
Materials | Case and contacting parts SUS304 | Case SUS202;Contacting parts SUS304 |
Dimension(L*W*H) | 670*850*1600mm | 670*850*1700mm |
Weight | 200KG | 200KG |
Bag sample as below:
FAQ:
01:How to operate the machine?We start to use the machine at the first time?
Answer:We have operation video and instruction book to you with the machine,if you need a engineer to install the machine,we also can dispatch a engineer to your factory,just the visa fee and round tickets fee under your cost.
02.How to repair or change when some parts are broken?
Answer:Factory will make fixed video as the problems the users mentioned
03:How to maintain the machine?
Answer:Maintain manual will note how to do for users
04:How to choose the most suitable packing machine?
Answers:It deepends on the products.Weight of package,and bag type and bag’s size
