Automatic Special Irregular Shape Skin Cream Sachet Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Automatic Special Irregular Shape Skin Cream Sachet Packing Machine,To be suitable for all kinds of liquid,paste,sauce material in food industry,chemical and pharmacy industry.For example:.shampoo,facial cream,mask,one hair color,hair dye,peanut paste,ketchup,peanut butter,oil and vinegar.
Bag type is 4 side sealing with irregular bag type and packing weight is from 1ml to 30ml.machine is horizontal packaging machine.Normally for some small sachets.
Automatic Special Irregular Shape Skin Cream Sachet Packing Machine
Specifications for Automatic Special Irregular Shape Skin Cream Sachet Packing Machine
Model Number | HY-Y30 |
Filling Range | 1-20ml |
Sachet size | W:30-65mm L:30-120mm |
Max. film width | 150mm |
Sachet type | Irregular shape sachet |
Filling method | Pneumatic pump / magenetic pump |
Capacity | 25-40 ppm |
Power Voltage and consumption | 220V50-60HZ/2KW |
Air pressure and consumption | 0.35m³/min 0.6-0.8Mpa |
Dimension(L*W*H) | 2041X703X1679mm |
Weight | 350KG |
Packaging film materials | PE laminated film, such as PET/AL/PE, PET/PE, Nylon/PE, etc. Thickness: 0.08~0.12mm(3 or 4 layers) Inner core diameter：75mm Outer roll diameter：300mm |
Function for Automatic Special Irregular Shape Skin Cream Sachet Packing Machine：
1，Automatic weighting, filling , sealing ,making bag ,printing date and batching number,output counting is available
2，Packing material: PE + paper +pet/ PE + PET/ AL Foil / PE + Nylon + PET / Filter paper ect.
3，Driven type:Pneumatic( Air Consumption:0.4m³/min,Air compressor: 0.6- 0.8Mpa)
4，Used for all kinds of liquid materials in chemical industry,pharmacy and foodstuff industry,To pack them into any customized shaped bags.
Features for Automatic Special Irregular Shape Skin Cream Sachet Packing Machine
With Siemens‘s touch screen displayed with English language, can easily set and change the packing parameters. Daily production output and self-diagnostic machine error can be directly seen on screen.
2.High sensitive fiber optic senor can automatically trace color mark accurately.
3.Servo motor control system, pump, trimming die and stamper, more stable than the common machine.
4.Good performance, low noise, clear sealing texture and strong sealing performance.
5. Material is SS304,no any contaminated material,in line with international food and drug standard.
6. one years warranty,parts will be offered freely in this period,as well as express charge (Except men-made damage and damagable parts such as heat tube,protect tube,blade,etc)Customer case:
we are working with many big cosmetic company,like hanho in China,they pack these small nice design bag as a sample to their customer with their product.To be honest,this really a good idea.it can attact many customers.we can send you drawing like following once get your bag type design.
About Guangzhou heyi packing machine factory:
Established in year 1999, located in Baiyun Distrcit, Guangzhou HEYI PACK Co., Ltd. is specialized in designing, manufacturing and sales of automatic form-fill-seal sachet packaging machines, widely used in chemical, pharmaceutical, food, health products, cosmetics and other processing and production industries. With experienced hardware and software engineers, we are capable of both ODM & OEM production.
Main products: liquid packaging machine, granule packaging machine, powder packaging machine, tablets packaging machine, multi-material packaging machine, multi-lane packaging machine etc.,
Sachet types: Three sides seal sachet, four sizes seal sachet, pillow stick sachet, irregular shape sachet, etc.
