Irregular Shape Sachets Cosmetics Sample Bag Filling Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Irregular Shape Sachets Cosmetics Sample Bag Filling Packing Machine，irregular shaped bag type is a new bag design in this market.irregular shaped bag type packing machine is our main product.we have a strong experience to do this kind of packaging machine.
Good service will be provided to you.just need your packing idea,we provide the best machine for you.
Irregular Shape Sachets Cosmetics Sample Bag Filling Packing Machine
Machine introduction for Irregular Shape Sachets Cosmetics Sample Bag Filling Packing Machine
1.This irregular shape bag pakcing machine can finish all the functions ,such as bag making, measuring,filling,sealing,cutting and counting automatically.
2.Controlled by computer and stepping motor pulling bag, making bag by setting length or tracking cursor,the length of bag can be set and be cut at any time, no need to be trailed operation on one step, and save time and film;
3.Separate PID control temperature,better suitable for various package materials.
4. Optional parts: ribbon printer, rotary cutter, small cutter, former beating device, batch pneumatic cutter.
5.Simple driven system, working more stable and easy to maintain.
6. Packing material:(PET/PE), (Paper/PE), (PET/AL/PE), (OPP/PE)
Specifications for Irregular Shape Sachets Cosmetics Sample Bag Filling Packing Machine
Model | HY-IY420 | HY-IY620 |
Filling range | 1-20ml/10-30ml | 1-20ml/10-50ml |
Lanes | 1by1/1by2/1by3/1by4 | 1by3/1by4/1by5/1by6 |
Sachet size | W：25-90mm L：30-170mm | W:30-86mm L:30-170mm |
Max. film width | 420mm | 620mm |
Sachet type | Irregular shape sachet | Irregular shape sachet |
Filling method | Pneumatic pump / magnetic pump | Pneumatic pump / magnetic pump |
Capacity | 80-100 PPM | 80-150 PPM |
Power Voltage and consumption | 220V50-60HZ/4.5KW | 220V50-60HZ/5.5KW |
Air pressure and consumption | 0.6m³/min 0.6-0.8Mpa | 0.6m³/min 0.6-0.8Mpa |
Dimension(L*W*H) | 1500*1400*2155mm | 1700*1400*2160mm |
Weight | 550KG | 600KG |
Packaging film materials | PE laminated film, such as PET/AL/PE, PET/PE, Nylon/PE, etc. Thickness: 0.08~0.12mm(3 or 4 layers) Inner core diameter：75mm Outer roll diameter：300mm-500mm | |
Main brand:
Bag sample:
After sale service:
1. For our machines, we will provide some spare parts and easy broken parts free of charge when delivering.
2. We will have one year free warranty period. During warranty period, if there is any malfunction for the machine, we will try our best to solve the problem within 24 hours. If there are some spare parts needed to be replaced, we will provide the spare parts for free. Beyond warranty, we will charge the cost price for spare parts. We provide technical support for our machines for life-long time.
3. We can provide installation and maintenance service at your place if you need.
Company information:
We are a factory with 20 years packing machine,establised in 1999,have many kinds of packing machine,granular packing machine,liquid packing machine,powder packing machine.bag type with 3 side sealing bag type,4 side sealing bag type,stick back sealing bag type,round corner bag type,irregular shaped bag type.
Just give us your packing idea,we will provide the perfect machine to you.
Our company,whole building is our workshop:
This is our engieers team
Our workshop
Packing machine and prepare to ship
