Multi Lanes Stick Pack Form Fill And Seal Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Multi Lanes Stick Pack Form Fill And Seal Packing Machine,Features:
1. Adopt German Siemens PLC controller, color touch screen operation; Taiwan AIRTAC cylinder; France Schneider switching power supply;
2. Servo heat sealing bag, vertical sealing without stickers, exquisite bag type;
3. Material: The contact part of the box and material is made of SUS304 stainless steel, which is in line with GMP production.
4. The heat-generating parts and moving parts are hidden in the protective cover, which is safe and reliable.
5. The equipment is equipped with casters for easy handling and movement.
Multi Lanes Stick Pack Form Fill And Seal Packing Machine
Guangzhou Heyi pack company's machines form, fill and seal back side sealing stickpacks for powders, granulates, liquids and pasty products for dairy, food, cosmetics and pharmaceutical industries.all plastic film bags is OK for our autonatic packing machine.
This stikc pack packing machine with main frame and is driven by servo motors engines. The reel is enclosed inside the cabinet to dust from entry. The machine is manufactured according to the most demanding rules in order to comply with the most strict norms and rules.
Application for Multi Lanes Stick Pack Form Fill And Seal Packing Machine
It is suitable for automatic packaging of powder products with poor fluidity in food, health care and pharmaceutical industries, such as: freeze-dried powder, protein powder, gastrodia powder, pueraria powder, stone meal powder, notoginseng powder, whole grain powder, meal replacement powder , milkshake powder, ganoderma powder, bear bile powder, milk powder, coffee powder, solid beverage, etc.
Specifications for Multi Lanes Stick Pack Form Fill And Seal Packing Machine
Model | HY-YF520 | HY-YF720 |
Filling range | 1-20ml | 1-50ml |
Rows | 1by6 | 1by6, 1by8, 1by10 |
Sachet size | W：25-38mm L：30-170mm | W：25-55mm L：30-170mm |
Max. film width | 520mm | 720mm |
Sachet type | Stick with round corners | Stick with round corners |
Filling method | Auger screw | Auger screw |
Capacity | 120-180ppm | 200-300ppm |
Power Voltage and consumption | 220V50-60HZ/4.5KW | 220V50-60HZ/4.5KW |
Air pressure and consumption | 0.6m³/min 0.6-0.8Mpa | 0.6m³/min 0.6-0.8Mpa |
Dimension(L*W*H) | 1410*1700*2500mm | 1540*1700*2500mm |
Weight | 600KG | 650KG |
Packaging film materials | PE laminated film, such as PET/AL/PE, PET/PE, Nylon/PE, etc. Thickness: 0.08~0.12mm(3 or 4 layers) Inner core diameter：75mm Outer roll diameter：500mm | |
Packing speed(production capacity) is about 300 stick packs per minute
The Vertical Form Fill Seal multilane packaging machine for stick pack is the most popular machine in this market. It has great reliability and the most advanced packing technology that allows a high performance with special requirements.as long as you have the packing requirments,we will do the matched machine for you.Just do the best for you.
Besides being less complex in construction, it is also easier to operate no matter powder packaging machine, granular packaging machine or liquid packaging machine
Ask us how this vertical Form Fill Seal multilane packaging machine for stick pack and others in the range can cover your production needs and all the available options through our contact form.
Bag sample:
