Small Sachet Pouch Bag Side Sealing Honey Packing Machine
- HEYI
- Guangzhou
- 15 days
- 500sets/month
Small Sachet Pouch Bag Side Sealing Honey Packing Machine
Automatic vertical honey packaging machines for all needs.we are bringing innovation to the world of vertical packing machine market since 1999.In order to adapt the production of automatic vertical packaging machines to the market needs, we implement power supply groups to allow the existing packaging system to elaborate complementary products.
Vertical fill form and seal ketchup packaging machinery. 4 Side Seal Sachet , stick pack and turn key complete packaging lines for ketchup or similar viscous products
Small Sachet Pouch Bag Side Sealing Honey Packing Machine
Standard Features for liquid packing machine：
* easy pack control and automatic alarming function.
* Two language screen display, easy operation.
* High sensitivity photoelectric eye color tracing,more accuracy.
* Bag type can be customised to 3 sides sealing, 4 sides sealing, pillow bag ,and long stick bag.
* Famous brand components, ensure the quality and durability of machine.
* Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.
* Ribbon code printer, link-bag device is option.
* Multipurpose packaging, suitable for various packaging of different product.
Remark:Honey is special,per your product,heater is optional
Main parts brand:
Bag sample:
Specifications for Small Sachet Pouch Bag Side Sealing Honey Packing Machine
Model | HY-QY50 | HY-Y50 |
Filling range | 1-50ml | 1-50ml |
Sachet size | W：30-100mm L：30-150mm | W：30-100mm L：30-150mm |
Max. film width | 220mm | 220mm |
Sachet type | 3 sides / 4 sides | 3 sides / 4 sides |
Filling method | Piston pump / magnetic pump | Piston pump / magnetic pump |
Control | SIEMENS PLC + TOUCH SCREEN | EASY PACK CONTROL |
Capacity | 30-50ppm | 30-50ppm |
Power | 220V50-60HZ/1.0KW | 220V50-60HZ/1.0KW |
Air | 0.3m³/min 0.6-0.8Mpa | 0.3m³/min 0.6-0.8Mpa |
Materials | Case and contacting parts SUS304 | Case SUS202;Contacting parts SUS304 |
Dimension(L*W*H) | 880*700*1750mm | 670*850*1655mm |
Weight | 250KG | 200KG |
Features for Small Sachet Pouch Bag Side Sealing Honey Packing Machine
1. Using a rotary cutter to cut, by replacing the blade, the flat mouth and the serrated mouth effect can be realized, and the bag length cutting position is convenient to adjust;
2. Full pneumatic control including metering and bag making, simple operation, less wear parts in the later period, reducing parts replacement;
3. Material: The material contact part is made of SUS304 stainless steel, which meets the requirements of GMP production.
4. The heat-generating parts and moving parts are hidden in the protective cover and are safe to operate.
5. The equipment is equipped with casters for easy handling and movement.
Package and Shipment
*Put the machine onto bottom iron support
*Bind foot stool with iron bar on the bottom support by iron wire tightly.
*Pack the complete machine into container by forklift truck.
*Deliver them by sea or by air
*30sets/20 feet Container
FAQ for honey sachet packing machine
01:How to operate the machine?We start to use the machine at the first time?
Answer:We have operation video and instruction book and also have engineers to user’s company
02.How to repair or change when some parts are broken?
Answer:Factory will make fixed video as the problems the users mentioned
04:How to choose the most suitable packing machine?
Answers:Send us your packing idea,what do you want to pack?what kind of the bag type and how about your bag size.
Payment term is 30% TT in advance,70% balanced payment before shipping.
Our company as below:
